Development Goal

The UHP Tyre

Performance Specification

Not only excellent driving stability and comfort mute performance for the design of the main line, But also the asymmetric fashion pattern design, the performance of different patterns on both sides co-operate with each other improve the mutual promotion.at the same time we made improvement in the formula and tyre carcass structure, So we can fully meet the luxury car on the comfortable performance requirements.

Main Performance Product Size





1、Super Driving Stability and Handling

Through the optimal formula and pattern structure design, ensuring the superior stability and handling performance of the tyre.

A.Apply the white carbon and high content natural rubber on the formula to adjust the hardness of tread and with the small groove design on the pattern to reduce the overall hardness of the tread block and increase the imprint area of the tread.

B.With the asymmetrical tread design enhancing surface sliding resistance ,and continuous transverse groove ensures stability and accuracy.















2、Excellent Mute and Comfor

Through the design of the optimum carcass structure and pattern structure, ensuring the optimum mute and comfort performance

A.Optimize the carcass structure and strengthenging the force balance of the tyre during the driving process by analyzing the force of each part of the tyre in the contest.

B.Asymmetrical pattern design combined with the open pattern block design can effectively improve the mute of the tyre and reduce the noise.













3、Excellent Wet Grip and Dry Brake

Through the optimum formula and pattern design, the brake performance ,the wet grip and the dry peformance can be ensured

A.Apply high white carbon formula to improve the brake performance of special wetlands.

B.The enhanced carcass structure of the tire together with a broad, rugged shoulder pattern and stiffener groove base ,ensuring the rigidity of the tires during driving and steering.

C.Through computer simulation of the tyre tread and surface force analysis and increase the greatest extent tread imprint area, to ensure the tyre maximum contact area in the road.



Series SIZE Load index Speed rating PR SW Extra Load Tread depth(MM) Max. pressure(kPa) Standard rim(ins)
30 235/30ZR20 88 Y - - XL 8.0  340 8½J
235/30ZR22 90 W - - XL 8.0  340 8½J
245/30ZR20 95 W - - XL 8.0  340 8½J
245/30ZR22 92 W - - XL 8.0  340 8½J
255/30ZR22 95 W - - XL 8.0  340 9J
265/30ZR22 97 W - - XL 8.0  340 9½J
275/30ZR20 97 W - - XL 7.5  340 9½J
285/30R22 101 V - - XL 8.0  320 10J
295/30ZR22 103 W - - XL 8.0  340 10½J
35 225/35ZR20 95 W - - XL 8.0  340 8J
245/35ZR20 95 Y - - XL 8.0  340 8½J
265/35R22 102 V - - XL 8.0  320 9½J
285/35ZR22 106 W - - XL 8.5  340 10J
295/35ZR21 107 W - - XL 8.0  340 10½J
295/35ZR21 107 Y - - XL 8.0  340 10½J
315/35ZR20 110 W - - XL 8.0  340 11J
40 255/40ZR20 101 W - - XL 8.0  340 9J
265/40R22 106 V - - XL 8.5  320 9½J
275/40ZR20 106 W - - XL 8.0  340 9½J
295/40ZR21 111 W - - XL 8.0  340 10½J
305/40R22 114 V - - XL 8.5  320 11J
45 255/45ZR19 104 W - - XL 7.5  340 8½J
255/45ZR20 105 W - - XL 8.0  340 8½J
275/45ZR21 110 W - - XL 7.5  340 9J
275/45R22 112 V - - XL 8.5  320 9J
285/45ZR21 113 W - - XL 7.5  340 9½J
285/45R22 114 V - - XL 8.5  320 9½J
295/45ZR20 114 W - - XL 8.0  340 10J
305/45ZR20 116 W - - XL 8.5  340 10J
305/45R22 118 V - - XL 9.0  320 10J
50 235/50ZR19 99 W - - 7.5  300 7½J
245/50R19 105 V - - XL 8.0  340 7½J
255/50ZR20 109 W - - XL 7.5  340 8J
265/50R20 111 V - - XL 8.5  320 8½J
* 275/50ZR21 113 W - - XL 7.5  340 8½J
55 235/55R20 105 H - - XL 7.5  340 7½J
275/55R20 117 V - - XL 8.5  320 8½J


* COMING SOON

All the data are subject to change by the manufacturer without further notice.
